Product Summarize
SG-10XM Multi-Conveyor Line Check Weigher for Stick Packaged Product are capable of checking the weight and fill level of up to 700 packaged products per minute on up to 10 lanes, allowing manufacturers to increase production speeds.Welcome to consult for quotation information!
Product Parameter
Type:SG-10XM
Weighing scope: 2-300g
Restrictions of product:L:180 W:40 H:2-20(mm)
Accuracy:±0.01g (Depends on products)
Division scale:0.01g
Belt width:30mm
Highest speed:70pcs/min(one lane)
Weight of machine:about 200Kg
Powder supply：AC220V 50HZ
Power:about 300W
Main material:SUS304(Stainless Steel)
Multi-channel passing products to improve production efficiency (the number of channels can be customized)
Product Characteristics
1. It is suitable for multi-row simultaneous automatic weight detection of small packaging products such as food, medicine, and daily necessities
2. Greatly improved the detection speed per unit time
3. Effectively prevent empty bags, underweight, overweight and other defective products
4. Count the passed products, and automatically remove unqualified products by the sorting device
5. It can be matched with multi-column packaging machines, automatic filling machines, metal detectors, etc.
6. Customized according to the requirements of the on-site production line, and can be configured with automatic barcode scanning and inkjet system
7. The number of detection columns can be customized according to customer needs (such as double columns, four columns, six columns, ten columns, etc.)
8. Each channel can eliminate unqualified products separately.
9. The number of consecutive unqualified products in each channel can be modified.
10. Statistical data of each channel: real-time result display, trend graph display, and histogram display.
